MQ Heat Resistant Heat-treated Fiberglass Sleeving is braided by E grade glass fiber, then lock weave by impregnated with special resin. Widely used on household appliances and automobile. Working temperature: - 94℉ (70℃) ~ 1022℉ (550℃).
Item No :
MQHTF-SOrder(MOQ) :
100mPayment :
TT, LC, PaypalProduct Origin :
ChinaColor :
Red, blue, green, yellow, black, silverShipping Port :
Shanghai, Ningbo, QingdaoLead Time :
Abundant stocks, can be dispatched out immediately.Description
MQ Heat-treated Fiberglass Sleeving is braided by E grade glass fiber, then lock weave by impregnated with special resin. Which possesses excellent high temperature resistance and good mechanical property.
Application
MQ Heat-treated Fiberglass Sleeving is widely used to protect wires from high temperature and occasional flame on electric motor, household appliances and automobile.
Technical Data
| Thermal Class | C |
| Size/Inner diameter | 1mm-30mm |
| Color | White, other colors can be customized. |
| Working temperature | - 94℉ (70℃) ~ 1022℉ (550℃) |
| Breakdown voltage | 1KV |
| Properties | High temperature & flame resistant, anti-aging, acid and alkali resistant. |
Specification
| Part No. | Inner Dia./mm | Thickness / mm | Roll Length / m | |
| Nominal | Tolerance | |||
| MQHTF-S-010 | 1 | +0.30 | 0.30±0.12 | 100 |
| MQHTF-S-015 | 1.5 | |||
| MQHTF-S-020 | 2 | 0.40±0.15 | ||
| MQHTF-S-025 | 2.5 | |||
| MQHTF-S-030 | 3 | |||
| MQHTF-S-040 | 4 | |||
| MQHTF-S-050 | 5 | +0.50 | 0.45±0.15 | |
| MQHTF-S-060 | 6 | |||
| MQHTF-S-070 | 7 | |||
| MQHTF-S-080 | 8 | |||
| MQHTF-S-090 | 9 | |||
| MQHTF-S-100 | 10 | +1.0 | 0.60±0.20 | 50 |
| MQHTF-S-120 | 12 | |||
| MQHTF-S-130 | 13 | |||
| MQHTF-S-140 | 14 | |||
| MQHTF-S-160 | 16 | |||
| MQHTF-S-180 | 18 | +2.0 | 0.64±0.22 | |
| MQHTF-S-200 | 20 | |||
| MQHTF-S-220 | 22 | |||
| MQHTF-S-250 | 25 | |||
| MQHTF-S-300 | 30 | 0.66±0.22 | ||
